M-3S.OI12.05
 |
| Screen Size, inch/cm |
12.1/31 |
| Brightness, cd/m2, not less than |
150 |
| Contrast, not less than |
300:1 |
| Resolution, pixel, not less than |
800x600 |
| Viewing Angles, °, not less than: |
- horizontal |
±80 |
| - vertical |
+80 |
| Supply Voltage, V/Hz |
+27 |
| Power Consumption, W, not more than |
-at standard climatic conditions |
20 |
| -when temperature is below 0°С |
60 |
| Interfaces |
VGA |
| Ambient Temperature, °С |
- operating |
-10…+55 |
| - limiting |
-40…+70 |
| Operating Conditions as per GOST RV 20.39.304-98 |
groups: 2.1.1, 2.3.1 |
| Weight, kg, not more than |
4,2 |
| Dimensions, WхHхD, mm |
328х245х72 |
| Additional Functions |
Touch Input (RS-232) Setting Control (RS-232) |
| Installation |
flange-mounted |
| Development Stage |
Letter О1 Included into the Coordination Target Program 'Integratsiya-SVT-2015' |
|
|
|
|
